OUTDOOR – ET SERIES
ET SERIES
- Dual voltage LED Displays
- Dimension: 960 x 960 x 88mm
- Pixel Pitch: 6.67mm, 8mm, 10mm
- 10,000 Nits Ultra High Brightness
- IP66 Ingress Protection (Front & Rear)
- Dual-voltage LEDs
- Heat-sink Based Thermal Management
- Slim, Fan-less Die-cast Cabinets
- Common Hub Card To Upgrade Flexibility
PRODUCT HIGHLIGHTS
Bright, Reliable, and Built to Last
High-brightness LED displays with die-cast aluminum housing for maximum daytime visibility, easy installation, and long-lasting, reliable performance.
Cable free modules
All cables are neatly routed through the bottom of the cabinet, ensuring a clean, clutter-free appearance while minimizing the risk of accidental disconnection.
IP66 Rated – Front & Back Protection
With IP66 rating on both sides and rugged weatherproof cabinets, these LED displays are built to resist dust, rain, and extreme conditions.
Maximum Efficiency with Dual voltage LED
Using 3.2V for red and 4.2V for green and blue LEDs—compared to the traditional 5V across all—our technology helps save power consumption by at least 30% without compromising brightness.
Perfectly Seamless. Immersive in Every Angle
Engineered for curves and L-shaped corners, our seamless corner cabinets enable stunning naked-eye 3D visuals from every angle.
Smarter Power. Zero Wastage
Powered by intelligent distribution, energy-saving ICs, and high-efficiency PFC supplies for peak performance with minimal energy loss.
MECHANICAL DIMENSIONS
SPECIFICATIONS
| Model Name | ET - 6.67 | ET - 8 | ET - 10 | ET Pro - 6.67 | ET Pro - 8 | ET Pro - 10 | ET Ultra - 6.67 |
|---|---|---|---|---|---|---|---|
| Pixel Pitch (mm) | 6.67 mm | 8 mm | 10 mm | 6.67 mm | 8 mm | 10 mm | 6.67 mm |
| Cabinet Dimension (W x H x D) mm | 960 x 960 x 88 | 960 x 960 x 88 | 960 x 960 x 88 | 960 x 960 x 88 | 960 x 960 x 88 | 960 x 960 x 88 | 960 x 960 x 88 |
| Weight (kg/m²) | 23 | 24 | 22.6 | 23 | 22.5 | 22.5 | 22.6 |
| Service Access | Front / Back | Front / Back | Front / Back | Front / Back | Front / Back | Front / Back | Front / Back |
| Maximum Brightness (nits) | 7500 | 7500 | 7500 | 9000 | 10000 | 10000 | 15000 |
| Viewing Angle | 160 x 160 | 160 x 160 | 160 x 160 | 160 x 160 | 160 x 160 | 160 x 160 | 160 x 160 |
| Contrast Ratio | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Max Power (Watts/m²) | 531 | 521 | 510 | 564 | 553 | 543 | - |
| Refresh Rate (Hz) | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 |
| Ingress Protection | Front IP66 / Back IP66 | Front IP66 / Back IP66 | Front IP66 / Back IP66 | Front IP66 / Back IP66 | Front IP66 / Back IP66 | Front IP66 / Back IP66 | Front IP66 / Back IP66 |
| Cabinet Type | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame | Die-Cast Al + Steel Frame |
| Data Processing | 16 Bit | 16 Bit | 16 Bit | 16 Bit | 16 Bit | 16 Bit | 16 Bit |
Comes in Multiple variants, standard and high brightness
These specifications are standard and can be customized. May change without prior notice.
